CHANNEL
Filter By
Flange Width
unit weight
Channel Size
| Description | Length | Channel size | Flange width | Unit weight |
|---|---|---|---|---|
| 1 1/2″ X 1/2″ X 1/8″ BAR CHANNEL | 1/2 | 1/2 | 1.12 | |
| 1 1/4″ X 1/2″ x 1/8″ BAR CHANNEL | 11/4 | 1/2 | 1.01 | |
| 1″ x 1/2″ x 1/8″ BAR CHANNEL | 1 | 1/2 | 0.84 | |
| 10 X 15.3# CHANNEL | 10 | 2.6 | 15.3 | |
| 10 X 20# CHANNEL | 10 | 2.739 | 20 | |
| 10 X 21.9# MISC. CHANNEL | 10 | 3.45 | 21.9 | |
| 10 X 22# MISC. CHANNEL | 10 | 3.315 | 22 | |
| 10 X 25# CHANNEL | 10 | 2.886 | 25 | |
| 10 X 25# MISC. CHANNEL | 10 | 3.405 | 25 | |
| 10 X 28.5# MISC. CHANNEL | 10 | 2.95 | 28.5 | |
| 10 X 30# CHANNEL | 10 | 3.033 | 30 | |
| 10 X 33.6# MISC. CHANNEL | 10 | 4.100 | 33.6 | |
| 10 X 41.1# MISC. CHANNEL | 10 | 4.32 | 41.1 | |
| 10 X 6.5# JR. CHANNEL | 10 | 1.125 | 6.5 | |
| 10 X 8.4# JR. CHANNEL | 10 | 1.5 | 8.4 | |
| 12 X 10.6# JR. CHANNEL | 12 | 1.5 | 10.6 | |
| 12 X 10.6# MISC. CHANNEL | 12 | 1.5 | 10.6 | |
| 12 X 20.7# CHANNEL | 12 | 2.94 | 20.7 | |
| 12 X 31# MISC. CHANNEL | 12 | 3.67 | 31 | |
| 12 X 32.9# MISC. CHANNEL | 12 | 3.500 | 32.9 | |
| 12 X 35# MISC. CHANNEL | 12 | 3.767 | 35 | |
| 12 X 40# MISC. CHANNEL | 12 | 3.89 | 40 | |
| 12 X 45# MISC. CHANNEL | 12 | 4.012 | 45 | |
| 12 X 50# MISC. CHANNEL | 12 | 4.135 | 50 | |
| 13 X 31.8# MISC. CHANNEL | 13 | 4 | 31.8 | |
| 13 X 35# MISC. CHANNEL | 13 | 4.072 | 35 | |
| 13 X 40# MISC. CHANNEL | 13 | 4.185 | 40 | |
| 13 X 50# MISC. CHANNEL | 13 | 4.412 | 50 | |
| 15 X 33.9# CHANNEL | 15 | 3.4 | 33.9 | |
| 18 X 42.7# MISC. CHANNEL | 18 | 3.95 | 42.7 | |
| 18 X 45.8# MISC. CHANNEL | 18 | 4 | 45.8 | |
| 18 X 51.9# MISC. CHANNEL | 18 | 4.4 | 51.9 | |
| 18 X 58# MISC. CHANNEL | 18 | 4.2 | 58 | |
| 2″ x 1″ x 1/8″ BAR CHANNEL | 3 | 1 | 1.59 | |
| 2″ x 1″ x 3/16″ BAR CHANNEL | 2 | 1 | 2.32 | |
| 2″ x 1/2″ x 1/8″ BAR CHANNEL | 2 | 1/2 | 1.47 | |
| 3 X 3.5# CHANNEL | 3 | 1.36 | 3.5 | |
| 3 X 4.1# CHANNEL | 3 | 1.41 | 4.1 | |
| 3 X 5.0# CHANNEL | 3 | 1.498 | 5 | |
| 3 X 6.0# CHANNEL | 3 | 1.596′ | 6 | |
| 3 X 7.1# MISC. CHANNEL | 3 | 1.938 | 7.1 | |
| 4 X 13.8# MISC. CHANNEL | 4 | 2.5 | 13.8 | |
| 4 X 4.5# (LIGHTER) CHANNEL | 4 | 1.52 | 4.5 | |
| 4 X 5.4# CHANNEL | 4 | 1.58 | 5.4 | |
| 4 X 6.25# CHANNEL | 4 | 1.647 | 6.25 | |
| 4 X 7.25# CHANNEL | 4 | 1.72 | 7.25 | |
| 5 X 6.7# CHANNEL | 5 | 1.75 | 6.7 | |
| 5 X 9.0# CHANNEL | 5 | 1.885 | 9 | |
| 6 X 10.5# CHANNEL | 6 | 2.034 | 10.5 | |
| 6 X 12.0# MISC. CHANNEL | 6 | 2.497 | 12 | |
| 6 X 13# CHANNEL | 6 | 2.157 | 13 | |
| 6 X 15.1# MISC. CHANNEL | 6 | 2.938 | 15.1 | |
| 6 X 15.3# MISC. CHANNEL | 6 | 3.5 | 15.3 | |
| 6 X 16.3# MISC. CHANNEL | 6 | 3 | 16.3 | |
| 6 X 18# MISC. CHANNEL | 6 | 3.5 | 18 | |
| 6 X 8.2# CHANNEL | 6 | 1.92 | 8.2 | |
| 7 X 12.25# CHANNEL | 7 | 2.194 | 12.25 | |
| 7 X 19.1# MISC. CHANNEL | 7 | 3.45 | 19.1 | |
| 7 X 22.7# MISC. CHANNEL | 7 | 3.6 | 22.7 | |
| 7 X 9.8# CHANNEL | 7 | 2.09 | 9.8 | |
| 8 X 11.5# CHANNEL | 8 | 2.26 | 11.5 | |
| 8 X 13.75# CHANNEL | 8 | 2.343 | 13.75 | |
| 8 X 18.7# MISC. CHANNEL | 8 | 2.975 | 18.7 | |
| 8 X 18.75# CHANNEL | 8 | 2.527 | 18.75 | |
| 8 X 20# MISC. CHANNEL | 8 | 3.025 | 20 | |
| 8 X 21.4# MISC. CHANNEL | 8 | 3.45 | 21.4 | |
| 8 X 22.8# MISC. CHANNEL | 8 | 3.5 | 22.8 | |
| 9 X 13.4# CHANNEL | 9 | 2.43 | 13.4 | |
| 9 X 23.9# MISC. CHANNEL | 9 | 3.45 | 23.9 | |
| 9 X 25.4# MISC. CHANNEL | 9 | 3.5 | 25.4 |
